BASIC RENDERED FLOOR PLAN
Materials and Price Listings for Reception, Conference, and Bathroom
Flooring: Stained Concrete
Sustainability: Concrete flooring is high in
durability and low in environmental impact; a perfect example of a material
that is beautiful, sustainable, economically friendly, durable and low in
maintenance. Not to mention it will last a lifetime! Concrete floors conserve
resources by functioning both as foundation slab and finished floor,
eliminating the need for carpeting or other floor coverings that would
eventually have to be replaced.
Installation: Stains can be applied
with either sprayers or paintbrushes. When using a spray tip, select one that
moves circularly from left to right, then right to left. The stain should be
scrubbed into the surface using a medium bristle brush in circular motion
immediately after being sprayed. Optional second spray following scrubbing will
help remove brush marks. This method ensures good penetration and minimal
marking from sprays or brushes. When applying stain with paintbrush, be sure to
minimize brush marks.
Maintenance: Once concrete floor is acid
stained, a concrete sealer is added to help resist water, staining, dirt, and
abrasions. Keeping concrete floors clean is relatively simple and inexpensive. Doug Demmert of Demmert and Associates recommends a
simple maintenance program of occasional dusting to remove grit and damp
mopping with a neutral cleaner to enhance the shine. Some manufacturers sell
special cleaners and conditioners for polished concrete that will not only
clean the surface, but also leaves behind a dirt-resistant film. These products
can be applied with a mop or auto scrubber and do not require buffing.
Calculations: Cost $6.00/Sq.ft.
v
Conference Room: 15.0 x 11.0 = 165sqft
v
Reception: 9.5 x 11.0 = 104.5 sqft
v
Bathroom: 5.5 x 8.5 = 46.75 sqft
§
Total Square Footage 165 + 104.5 + 46.75 = 316.25
§
Plus 10% Waste = 316.25 + 31 = 347.25
v
$6.00/sqft
§
347.25/6 = 2083.5
v
Total Cost: $2,083.5
Ceiling: Painted Dry Wall.
BEHR Premium Plus, Interior Flat. #105201
Sustainability: Ideal for ceilings.
Low odor, zero VOC, self-priming, ultimate durability, exceptional coverage, non-reflective,
mildew resistant finish, lifetime guarantee.
Installation: Paint on with roll
brush.
Maintenance: Clean with warm water
and soap.
Calculations:
v
Conference Room: 15.0 x 11.0 = 165sqft
v
Reception: 9.5 x 11.0 = 104.5 sqft
v
Bathroom: 5.5 x 8.5 = 46.75 sqft
§
Total Square Footage 165 + 104.5 + 46.75 = 316.25
v
2 coats of paint
§
316.25 x 2 = 632.5 sqft
v
1 gal covers 400ft
§
632.5/400 = 1.58 à 2 gallons
v
Cost $24.96/gal.
§
2 x 24.96 = 49.86
v
Total Cost: $49.86
Walls: Painted. YOLO
Colorhouse, Semi-gloss Interior Paint. #613313
Sustainability: Low odor, fast
drying, durable. Green Seal certified: No VOCs, phthalates, formaldehyde,
reproductive toxins, carcinogens, mutagen, hazardous air pollutants, or
ozone-depleting compounds.
Installation: Paint on with roll
brush
Maintenance: Clean with warm water
and soap.
Calculations:
v Conference Room: 15.0
x 11.0 = 165sqft
v
Reception: 9.5 x 11.0 = 104.5 sqft
v
Bathroom: 5.5 x 8.5 = 46.75 sqft
§
Total Square Footage: 165 + 104.5 + 46.75 = 316.25
§
10ft Ceiling Height: 316.25 x 10 = 3162.5 = 3163
v
1 gal covers 350-400 sqft
§
3163/350 = 9.037 à 9 gallons
v
2 coats: 2 x 9 = 18 à 18 gallons
v
Cost 18.95/gal
§
18 x 18.95 = 341.1
v
Total Coast: $341.1
Countertops: Stainless Steel (all countertops
throughout plan)
Sustainability: Finished product is
nontoxic and can be recycled, or salvaged for other projects/uses.
Installation: Stainless Steel is
cut out of sheet metal and bent to the desired shape. The sheet metal is then
attached to a plywood base using a strong glue or epoxy; this can also be done
with environmental friendly adhesives.
Maintenance: Wipe down with warm
water or clean with specialized stainless steel cleaner.
Calculations:
v
Reception: 10sqft
v
Conference: 24sqft
v
Total Square Footage: 34
v
Cost $66.50/Sq.ft.
§
66.50 x 34 = 2261
v
Total Cost: $2,261
Chair Upholstery: EnviroLeatherTM PVC-Free Faux Leather. #ELH – 943
Color: Turquoise
Sustainability: PVC free,
Plasticizer-Free, no heavy metals, passes indoor air quality requirement,
recycled, and renewable.
Installation: Upholstered
Maintenance: EnviroLeatherTM has
stain resistant, durable finish that is designed for easy care and cleaning.
Most stains can be easily removed by using a warm damp cloth with soap and
water. For stubborn stains, such as ink and grease, remove with rubbing
alcohol. Disinfecting can be done with a 20% bleach solution.
Calculations:
v
Average 3 Yards per Chair
v
10 Chairs
§
10 x 3 = 30 yard of fabric
v
Price Unavailable
Window Coverings: ECO Friendly Roman
Shades #111_0162
Color: Cinnamon
Stick
Sustainability: Insulating design
prevents solar heat gain, reducing energy consumption and lowering energy
bills. Blocks the suns UV rays that damage furniture and flooring. Fabrics free
of PVC, halogens, lead, formaldehyde, allergenic dyes, pesticides, phenols, or
heavy metals. All components are 100%
recyclable. Plastic contests contain up to 50% pre-consumer recycled material
and are packaged in 100% recyclable cardboard, which contains 35-40% previously
recycled contents.
Installation: inserted into window
frame
Maintenance: Shades can be vacuumed
to reduce dirt and dust, or spot cleaning using a damp cloth and upholstery
cleaner to remove stains on fabric.
Calculations:
v
4 Windows @ 3ft wide
v
1 shade to cover window
v
Cost $104.57 per shade
§
4 x 104.57 = 418.28
v
Total Cost: $418.28
